Modular Bitmain ANTRACK AR30 47U Hydro-Cooling Cabinet 200kW
ANTRACK AR30 is the 200kW hydro-cooling cabinet that transforms your mining operation into a heating asset. Contact our team today to discuss pricing, availability, and how this innovative solution can eliminate your heating costs.
$16,000.00
Not Fitting Your Site?
Tell us your mining capacity and site requirements, and we’ll recommend the right hydro-cooling container for your deployment.
Facebook
Twitter
LinkedIn
Pinterest
VK
Reddit
Modular 200kW hydro cooling cabinet with heat recovery function for Antminer
CONTAINER CAPACITY
ASIC MINERS
20 Units
Maximum loading capacity
POWER
200kw
High-power Container
VOLTAGE
380–480V
AC 50/60Hz
FORM FACTOR
47U
1.2 × 1.0 × 2.3 m dimensions
AVAILABILITY In stock, ready to ship • DDP Sea Shipping Available
Compatible Models
The Bitmain ANTRACK AR30 is a modular 47U hydro-cooling cabinet engineered specifically for heating applications. Serving as an ultra-efficient 200kW thermal generator, it converts 100% of continuous mining heat directly into your facility’s heating infrastructure—replacing traditional boilers and eliminating wasteful dry coolers.
200 kW Industrial Heating Solution
Turn 200kW Compute Directly Into Facility Heating
The ANTRACK AR30 is engineered specifically for heating, serving as an ultra-efficient 200kW thermal generator. Instead of expelling energy through wasteful dry coolers, 100% of the continuous mining heat is pumped directly into your facility’s heating infrastructure to replace traditional boilers.
Key benefits:
-
Zero waste – all mining heat is captured and reused
-
Replace boilers – eliminate fossil fuel heating costs
-
Dual purpose – mine Bitcoin while heating your facility
-
Ultra-efficient – 200kW of compute = 200kW of heat
Onboard Plate Heat Exchanger (PHE)
Zero Thermal Waste: Direct Hydronic Loop Integration
Equipped with a built-in plate heat exchanger, the AR30 safely isolates miner fluid while transferring heat straight to:
-
Radiant floors – comfortable, efficient space heating
-
Greenhouses – extend growing seasons, reduce heating costs
-
District water networks – contribute to community heating systems
How it works:
-
Miners generate heat – ASICs produce continuous thermal energy
-
Liquid cooling captures heat – hydro-cooling loops absorb thermal output
-
PHE transfers heat – plate heat exchanger isolates miner fluid from facility water
-
Your facility absorbs the heat – heating infrastructure receives clean, isolated thermal energy
-
Miners stay cool – simultaneous cooling and heating in one system
Your heating absorbs the heat—cooling the miners simultaneously.
Bitmain ANTRACK AR31 Parameters
Without package |
With package |
Weight |
| L:1000mm、W:1200mm、H:2300mm | L:1070mm、W:1380mm、H:2400mm | 780KG |
Specification
| Model | ANTRACK AR30 | Installed capacity | 20 units ANTMINER (U2 Hydro) or 14 units ANTMINER (Hydro) |
| Miner maximum load,kW | 200 kW | Total load,kW | 207 |
| Power supply AC input voltage,Volt | 380~480VAC | Power supply AC input frequency range,Hz | 50~60 |
| Maximum power supply AC input current,Amp | 315 @380V 249 @480V |
||
| Maximum heat exchange power,kW | 1340*570*1330 MM | Size (Length*Width*Height),mm | 490*235*250 |
| Diameter of water pipe connector,mm | DN50 | Coolant inlet temperature,°C | -20~45 |
| Water flow,L/min | 320~350 | Water pressure,bar | ≤3.5 |
| Working fluid | Organic Antifreeze (10%) | Installation distance,m | ≤5 |
| Liquid PH | 7.8~8.5 | Storage temperature,°C | -40~70 |
| Operation humidity(non-condensing),RH | 10~90% |
| Weight | 400 kg |
|---|---|
| Dimensions | 120 × 100 × 230 cm |
You must be logged in to post a review.
Where Is ANTRACK Applicable?
1. Supply power
2. Provide a heat source
3. INSIDE DATA CENTERS
ANTRACK AR30 200kW — Hydronic Heating Heat Recovery
Recover up to 200kW of waste heat from high-density computing. An isolated plate heat exchanger delivers 60°C–80°C hot water for building and process heating.
Applications
District Heating & Multi-Building Networks — Up to 200kW for commercial buildings, campuses, and residential areas.
Swimming Pools & Aquatic Centers — Continuous pool water heating, less conventional heating needed.
Aquaculture & Livestock — Stable water and space heating for RAS, aquaculture, and livestock facilities.
CTA: Contact us for a heat recovery assessment.
FAQs
The Bitmain ANTRACK AR30 is a modular 47U hydro-cooling cabinet engineered specifically for heating applications. Unlike traditional mining cabinets that expel waste heat through dry coolers, the AR30 functions as an ultra-efficient 200kW thermal generator—converting 100% of continuous mining heat directly into your facility’s heating infrastructure. It is designed to replace traditional boilers while simultaneously mining Bitcoin.
As a 47U cabinet, the AR30 is designed to house multiple hydro-cooled miners. The specific miner capacity depends on the model and configuration. For detailed capacity information, please contact an authorized Bitmain distributor.
The AR30 uses a four-step process to convert mining heat into usable facility heating :
-
Miners generate heat – ASICs produce continuous thermal energy
-
Liquid cooling captures heat – hydro-cooling loops absorb thermal output
-
PHE transfers heat – the built-in plate heat exchanger isolates miner fluid from facility water
-
Your facility absorbs the heat – heating infrastructure receives clean, isolated thermal energy
-
Miners stay cool – simultaneous cooling and heating in one system
The built-in Plate Heat Exchanger (PHE) is a critical component that safely isolates the miner cooling fluid from your facility’s water system. This separation ensures :
-
Zero cross-contamination between miner coolant and facility water
-
Clean thermal energy transferred to your heating infrastructure
-
Safe integration with existing hydronic heating systems
-
Simultaneous cooling and heating in one continuous process
The AR30’s 200kW thermal output can be integrated into various heating applications :
| Application | Benefit |
|---|---|
| Radiant floors | Comfortable, efficient space heating |
| Greenhouses | Extend growing seasons, reduce heating costs |
| District water networks | Contribute to community heating systems |
| Industrial processes | Pre-heating, drying, and other thermal needs |
By capturing and reusing 100% of mining heat, the AR30 transforms a cost center (heating) into a revenue-generating asset. The 200kW of thermal output can offset or eliminate facility heating costs, effectively reducing the net cost of mining operations while generating Bitcoin revenue.
