Bitmain ANTSPACE MD5: 160-Slot 1MW 40HQ Immersion Cooling Container
The Bitmain ANTSPACE MD5 is a 1MW 40HQ immersion cooling container with 160 slots, featuring a top-mounted dry tower and dual independent modules for stable, quiet, and efficient Bitcoin mining in any global climate. It provides a complete, integrated solution for professional mining operations requiring high-density deployment and advanced thermal management.
|
External dimensions |
Internal dimensions |
Weight |
| L:12192mm、W:2438mm、H:2896mm | L:12000mm、W:2230mm、H:2660mm | 12000 KG |
| Model | ANTSPACE MD5 | Installed capacity | 160 Rack Space |
| PUE(Power usage effectiveness), @25℃ ambient temperature | 1.06 | Input voltage and frequency | 400V±5% 50/60Hz |
| Main switch of power distribution cabinets, A | 1200*2 | Rated current, A | A: 952; B: 866 |
| Rated Current per Miner, A | 20 | Connection interface (Cooling Tower) | DN 65 (ISO2852 PN16） |
| Operating Power, kW | 100 | Motor Rated Voltage and Frequency | 400V±5% 50/60Hz |
| Outlet Temperature @30℃ ambient temperature | 35℃ (Outlet temp 5℃ above ambient temp) | Noise Level @25℃， 15m, dBA | 70 |
| Container certification | China Classification Society Certification | Safety certification | NFPA 79: 2024 UL 508A: 2018 R7.22 CSA C22.2 No. 301:23 ANSI/ISO 12100: 2012 EN ISO 12100: 2010 EN 60204-1: 2018 |
Key Specifications at a Glance
| Specification | Details |
|---|---|
| Manufacturer | Bitmain |
| Model | ANTSPACE MD5 |
| Container Type | 40HQ (40-foot High Cube) |
| Cooling Method | Immersion Cooling |
| ASIC Capacity | 160 Units (at full load) |
| Total Power | 1,000 kW (1MW) continuous electrical load |
| Form Factor | Custom / Standard 40HQ |
| Power Input | 380V–415V AC, 50/60Hz |
| Cooling | Immersion (Thermal Management) |
| Availability | Typical lead time 45 days |
| Shipping | DDP Sea Shipping Available |
Product Description
The Bitmain ANTSPACE MD5 is a 1MW immersion cooling container housing up to 160 Antminer units. Built as a 40HQ infrastructure, it provides a submerged liquid-cooling environment that ensures hardware thermal stability and silent operation.
The platform features an integrated 40-foot dry tower mounted directly on top for optimized heat dissipation. The internal structure is divided into two independent, symmetrical modules. This modular separation improves system redundancy, ensuring that maintenance or adjustments on one side do not interfere with the performance of the other.
Equipped with Smart PDUs and monitoring software, the MD5 is engineered for global deployment across diverse temperature zones. It offers a reliable turnkey solution for large-scale operations requiring professional-grade heat management and simplified onsite infrastructure assembly.
|
Immersion Cooling – Superior Thermal Management The MD5’s immersion cooling architecture delivers:
|
160 Antminer Units – High-Density Capacity With capacity for 160 ASIC miners, the MD5 enables:
|
1MW Continuous Power Capacity Designed for 1,000 kW continuous electrical load:
|
Top-Mounted Dry Tower – Optimized Heat Dissipation The integrated 40-foot dry tower mounted directly on top provides:
|
|
Dual Independent Modules – Enhanced Redundancy The internal structure is divided into two independent, symmetrical modules:
|
Smart PDUs & Monitoring Software Built-in intelligence for professional operations:
|
Global Deployment Ready Engineered for worldwide deployment:
|
| Weight | 12000 kg |
|---|---|
| Dimensions | 1219 × 243.8 × 289.6 cm |
| Manufacturer | Bitmain |
| BYTE | Delivery in 60 days |
You must be logged in to post a review.
The Bitmain ANTSPACE MD5 is a 40-foot high-cube (40HQ) all-in-one immersion cooling mining container designed for large-scale Bitcoin mining. Officially launched by Bitmain in December 2024, it accommodates up to 160 immersion miners (Antminer S21 Imm. or S21 XP Imm.) and provides a continuous 1 MW electrical load, making it a highly efficient, rapidly deployable turnkey immersion cooling solution.
The MD5 uses immersion cooling, fully submerging miners in dielectric coolant. The system integrates a top-mounted dry tower built directly onto the container for efficient heat dissipation.
The MD5‘s internal structure is divided into two independent, symmetrical modules. This modular separation improves system redundancy, ensuring that maintenance or adjustments on one side do not interfere with the performance of the other.
The container has obtained the following certifications:
-
Container Certification: CCS (China Classification Society)
-
Safety Certifications: NFPA 79: 2024, UL 508A: 2018 R7.22, CSA C22.2 No. 301:23, ANSI/ISO 12100: 2012, EN ISO 12100: 2010, EN 60204-1: 2018
These certifications confirm that the MD5 meets international electrical and mechanical safety standards for global deployment.
The incoming cables must withstand voltages above 600V:
-
L1/L2/L3/N Phases: Single-core cable 600kcMil (300mm²) × 4
-
PE Phase: Single-core cable 500kcMil (240mm²) × 2
The cooling tower connection uses DN 65 (ISO2852 PN16) standard interfaces.
The MD5 is equipped with smart PDUs and monitoring software, integrating multiple sensors to display real-time parameters such as temperature, coolant level, and power consumption. It supports remote monitoring and control. The system uses PLC control cabinets for automated management, making it suitable for centralized operations at large-scale mining farms.
