Bitmain DCTANK AW1 120kW Support 376 Asic Miners Air Cooling Container
Bitmain DCTANK AW1 is a high-capacity air-cooled container solution designed for large-scale data centers and crypto mining farms.
$69,500.00
The price of miner changes from time to time. Price may be low or high. Please consult us for the specific price, we will give you the best price in the market.
Due to tariff changes on Chinese products, we offer DDP shipping for ASIC miner orders (MOQ: 30 pcs) to buyers. For smaller quantities, please contact our sales team for better options.
Order 2 or more machines to save on shipping costs! Contact our sales team now to secure the best rates.
Facebook
Twitter
LinkedIn
Pinterest
VK
Reddit
- All miner include PSU
- Technical Support
- Low-value Declaration
- Machine detection
Bitmain DCTANK AW1: Industrial-Scale Mining Infrastructure
(376U Rack Space • 120kW Power • 1.11 PUE Efficiency)
The DCTANK AW1 redefines large-scale mining with data-center-grade infrastructure in a shipping container:
✅ 376U Rack Capacity – Holds 100+ Antminer S21 (120 TH/s each)
✅ 120kW IT Load – Powers ≈12 PH/s total hashrate
✅ 1.11 PUE Cooling – 40% more efficient than open-air farms
✅ -40°C to 45°C Operation – Arctic to desert ready
Why Enterprise Miners Choose Bitmain DCTANK AW1？
1. Data Center Performance
-
1.11 PUE vs. 1.3+ for traditional mining sheds
-
Pre-installed busbars – No electrician delays
2. Extreme Environment Ready
-
Arctic Mode: Free cooling below -10°C
-
Desert Mode: Handles 45°C ambient temps
3. Cluster-Ready Design
-
Stack 10+ containers for 1 EH+ farms
-
Hot-swappable components – <1hr maintenance
Bitmain DCTANK AW1 Specifications
Product Overview
| Model | DCTANK AW1 |
| Dimensions (l*w*h), mm | 6058×2438×2896 |
| Server capacity, U | 376 |
| Container certification | CCS |
| Safety certification | NFPA 79:2024 UL 508A:2018 R7.22 CSA C22.2 No. 301:23 ANSI/ISO 12100:2012 EN ISO 12100:2010 EN 60204-1:2018 |
| Input Voltage and Frequency | 400V±5% 50/60Hz |
| Total IT load, KW | 120 |
Detailed Characteristics
| Shipping weight, T | 4.6 |
| Main Switch of Power Distribution Cabinets(A) | 250×2 |
| Rated current, A | ≤405 |
| Number of server cabinets | 8 |
| Single cabinet capacity, U | 47 |
| Single cabinet power density, KW | 15 |
| Inlet cable | The incoming cable requires two three-phase, five-wire cables, each with the following requirements: L1 single core cable 350kcMil（185mm²） L2 single core cable 350kcMil（185mm²） L3 single core cable 350kcMil（185mm²） N Single-core cable 250kcMil（127mm²） PE single-core cable 250kcMil（127mm²） |
Specification Details For Cooling Tower
Product Overview
| Dimensions (l*w*h), mm | 6058×2438×2896 |
| PUE(Power usage effectiveness)@ 25℃ ambient temperature | 1.11 |
| Rated Cooling Capacity, kW | 120 |
| Container certification | CCS |
| Motor Rated Voltage and Frequency | AV 400V±5%; 50/60Hz |
Detailed Characteristics
| Shipping Weight, T | 5.8 |
| Operating Weight, T | 7.8 |
| Supply Air Temperature, ℃ | 25 |
| Return Air Temperature ,˚C | 38 |
| Water Consumption @ 25˚C, m3/h | 0.2 |
| Noise Level @ 25˚C, 15m, dBA | 75 |
| Operating Temperature ,˚C | -40~+45 |
| Operation Humidity, RH | 5%~95% |
| Weight | 4600 kg |
|---|---|
| Dimensions | 605.8 × 243.8 × 289.6 cm |
| Manufacturer | Bitmain |
